Product number: 24.0124-0210.1
|
EAN: 4006633315302
Properties
Alles weergeven
|
|
Height (mm)
Height (mm)
|
67.0 |
|
Outer diameter (mm)
Outer diameter (mm)
|
298.0 |
|
Inner diameter (mm)
Inner diameter (mm)
|
164.0 |
|
Brake disc type
Brake disc type
|
perforated/vented |
|
Brake disc thickness (mm)
Brake disc thickness (mm)
|
24.0 |
|
Num. of holes
Num. of holes
|
5 |
|
Bore Ø (mm)
Bore Ø (mm)
|
15.4 |
|
Bolt hole circle Ø (mm)
Bolt hole circle Ø (mm)
|
130.0 |
|
Paired article number
Paired article number
|
24.0124-0211.1 |
|
Min. thickness (mm)
Min. thickness (mm)
|
22.0 |
|
Surface
Surface
|
coated |
|
Appr. stamp
Appr. stamp
|
e1 90r-02c0640/1341 |
|
Centering diameter (mm)
Centering diameter (mm)
|
98.0 |
|
Machining
Machining
|
alloyed/high-carbon |
|
Weight
Weight
|
6.56 kg |
